Specification of Rubber Conveyor Belt BANDO
Conveyor Belt BANDO
STANDARD SIZE:
Belt width : 100 ~ 2.200 mm
Belt length : Min 30 meters
Top Cover thickness : 0 ~ 30 mm
Bottom Cover thickness : 0 ~ 30 mm
Number of ply : 1 ~ 8 ply
Belt strength : 100 ~ 2.800 kgf/cm
Packing weight : 20 ton max
Roll Diameter : 3.7 m max
Selection of canvas : EP and NN
Selection of cover rubber :
General Use : Grade M, JIS-S, JIS-G, JIS-L
Special Use : UIP, SAR, QB
Heat Resistance : HC 510 ~ HC 710
Oil Resistance : OR 210 ~ OR 220
Flame Resistance : FR 300J
Chemical Resistance : CR
Conveyor Belt
